前言

上一篇文章中,我们介绍了Spring IoC 的容器初始化过程 - IoC 容器初始化

本篇文章中,我们继续介绍Spring IoC 依赖注入的过程和源码解读。

还是如之前一样,为大家梳理一下步骤流程,以便于大家能在心里有个大概的脉络,更容易读懂源码,更容易抓住重点。

主要内容:

  • beanName 解析转换
  • 手动注册Bean检测
  • 双亲容器检测
  • 依赖初始化(递归)
  • ★ 创建singleton 实例
  • 对象实例化
  • 属性装配
  • 处理Bean创建之后的各种回调事件
  • ...

源码解析

上一章最后一节,容器初始化的倒数第二步,finishBeanFactoryInitialization(beanFactory)实例化所有单例,调用了getBean()方法来做singleton bean 的实例化操作。这就是Spring IoC 依赖注入的入口。

在开始之前,有一点需要提一下。前面我们是从容器初始化之后进来的,但实际操作中,我们有可能是在程序普通运行情况下,用ApplicationContext.getBean()去获取容器中bean。不要局限于刚刚的视角中。

现在让我们开始吧。

首先看看getBean()

源码位置:AbstractBeanFactory#getBean(String name)

	@Override
	public Object getBean(String name) throws BeansException {
		return doGetBean(name, null, null, false);
	}

doGetBean()

deGetBean()

  • beanName 解析转换
  • 检测 手动注册Bean
  • 双亲容器检测
  • 依赖初始化(递归)
  • 创建Bean createBean()
	protected <T> T doGetBean(
			final String name, final Class<T> requiredType, final Object[] args, boolean typeCheckOnly)
			throws BeansException {
		// 反正就是获取到真正beanName
        // 处理两个情况,1. 将别名转化成真的beanName;2. 把FactoryBean的前缀"&"给去了
		final String beanName = transformedBeanName(name);
		Object bean;

		// Eagerly check singleton cache for manually registered singletons.
        // 检测已经注册的Bean,保证不重复创建
		Object sharedInstance = getSingleton(beanName);
		if (sharedInstance != null && args == null) {
			if (logger.isDebugEnabled()) {
				if (isSingletonCurrentlyInCreation(beanName)) {
					logger.debug("Returning eagerly cached instance of singleton bean '" + beanName +
							"' that is not fully initialized yet - a consequence of a circular reference");
				}
				else {
					logger.debug("Returning cached instance of singleton bean '" + beanName + "'");
				}
			}
            // 这个方法还是有点逻辑的
            // 如果目前获得的sharedInstance 不是FactoryBean,那bean就赋值成sharedInstance,直接返回
            // 如果是FactoryBean就返回FactoryBean创建的实例,
            // 这个也是FactoryBean的知识点,我在我的另一篇文章也讲过了,
			bean = getObjectForBeanInstance(sharedInstance, name, beanName, null);
		}

		else {
			// Fail if we're already creating this bean instance:
            // 直接翻译:创建过了此 beanName 的 prototype 类型的 bean,那么抛异常
			// We're assumably within a circular reference.
            // 往往是因为陷入了循环引用
			if (isPrototypeCurrentlyInCreation(beanName)) {
				throw new BeanCurrentlyInCreationException(beanName);
			}

			// Check if bean definition exists in this factory.
            // 检查下这个BeanDefinition是否存在
			BeanFactory parentBeanFactory = getParentBeanFactory();
			if (parentBeanFactory != null && !containsBeanDefinition(beanName)) {
				// Not found -> check parent.
                // 当前容器没有这个BeanDefinition,去parent 容器去找
				String nameToLookup = originalBeanName(name);
				if (args != null) {
					// Delegation to parent with explicit args.
					return (T) parentBeanFactory.getBean(nameToLookup, args);
				}
				else {
					// No args -> delegate to standard getBean method.
					return parentBeanFactory.getBean(nameToLookup, requiredType);
				}
			}

			if (!typeCheckOnly) {
				markBeanAsCreated(beanName);
			}

			try {
                // 这个 getMergedLocalBeanDefinition 前面讲过哦
				final RootBeanDefinition mbd = getMergedLocalBeanDefinition(beanName);
				checkMergedBeanDefinition(mbd, beanName, args);

                // 先初始化依赖的所有 Bean,这个很好理解。
                // 注意,这里的依赖指的是 depends-on 中定义的依赖
				String[] dependsOn = mbd.getDependsOn();
				if (dependsOn != null) {
					for (String dep : dependsOn) {
						if (isDependent(beanName, dep)) {
                            // 这里循环依赖概念不要紊乱了
                            // 这里指的是通过 depends-on 定义造成的循环依赖,
                            // 我们另外一种类成员式的循环引用Spring是支持的
							throw new BeanCreationException(mbd.getResourceDescription(), beanName,
									"Circular depends-on relationship between '" + beanName + "' and '" + dep + "'");
						}
                        // 注册依赖关系
                        // 这么做的原因是Spring在即将进行bean销毁的时候会【首先销毁被依赖的bean】。
                        // 看SpringBean的初始化和销毁顺序就知道了,依赖关系的保存目的就是这个
                        // 依赖关系的保存是通过一个ConcurrentHashMap<String, Set>完成的,key是bean的真实名字。
						registerDependentBean(dep, beanName);
						try {
                            // 先去初始化被依赖项
                            // 递归然后反递归回来
							getBean(dep);
						}
						catch (NoSuchBeanDefinitionException ex) {
							throw new BeanCreationException(mbd.getResourceDescription(), beanName,
									"'" + beanName + "' depends on missing bean '" + dep + "'", ex);
						}
					}
				}

				// Create bean instance.
                // 如果是 singleton scope 的,创建 singleton 的实例
				if (mbd.isSingleton()) {
					sharedInstance = getSingleton(beanName, new ObjectFactory<Object>() {
						@Override
						public Object getObject() throws BeansException {
							try {
                                // 创建Bean的详情,等下拉出来单独说
								return createBean(beanName, mbd, args);
							}
							catch (BeansException ex) {
								// Explicitly remove instance from singleton cache: It might have been put there
								// eagerly by the creation process, to allow for circular reference resolution.
								// Also remove any beans that received a temporary reference to the bean.
								destroySingleton(beanName);
								throw ex;
							}
						}
					});
                    // 前面讲过了
					bean = getObjectForBeanInstance(sharedInstance, name, beanName, mbd);
				}

                // 如果是 prototype scope 的,创建 prototype 的实例
				else if (mbd.isPrototype()) {
					// It's a prototype -> create a new instance.
					Object prototypeInstance = null;
					try {
						beforePrototypeCreation(beanName);
						prototypeInstance = createBean(beanName, mbd, args);
					}
					finally {
						afterPrototypeCreation(beanName);
					}
					bean = getObjectForBeanInstance(prototypeInstance, name, beanName, mbd);
				}

                // 如果不是 singleton 和 prototype 的话,需要委托给相应的实现类来处理
                // 这里非重点,我们的重点是singleton的创建
				else {
					String scopeName = mbd.getScope();
					final Scope scope = this.scopes.get(scopeName);
					if (scope == null) {
						throw new IllegalStateException("No Scope registered for scope name '" + scopeName + "'");
					}
					try {
						Object scopedInstance = scope.get(beanName, new ObjectFactory<Object>() {
							@Override
							public Object getObject() throws BeansException {
								beforePrototypeCreation(beanName);
								try {
									return createBean(beanName, mbd, args);
								}
								finally {
									afterPrototypeCreation(beanName);
								}
							}
						});
						bean = getObjectForBeanInstance(scopedInstance, name, beanName, mbd);
					}
					catch (IllegalStateException ex) {
						throw new BeanCreationException(beanName,
								"Scope '" + scopeName + "' is not active for the current thread; consider " +
								"defining a scoped proxy for this bean if you intend to refer to it from a singleton",
								ex);
					}
				}
			}
			catch (BeansException ex) {
				cleanupAfterBeanCreationFailure(beanName);
				throw ex;
			}
		}

		// Check if required type matches the type of the actual bean instance.
        // 最后再检查下类型对不对,不对就抛异常了,对的话就返回
		if (requiredType != null && bean != null && !requiredType.isInstance(bean)) {
			try {
				return getTypeConverter().convertIfNecessary(bean, requiredType);
			}
			catch (TypeMismatchException ex) {
				if (logger.isDebugEnabled()) {
					logger.debug("Failed to convert bean '" + name + "' to required type '" +
							ClassUtils.getQualifiedName(requiredType) + "'", ex);
				}
				throw new BeanNotOfRequiredTypeException(name, requiredType, bean.getClass());
			}
		}
		return (T) bean;
	}

doCreateBean()

步骤概览:

  1. 开始是单例的话要先清除缓存;
  2. 实例化bean,将BeanDefinition转换为BeanWrapper;
  3. 使用MergedBeanDefinitionPostProcessor,Autowired注解就是通过此方法实现类型的预解析;
  4. 解决循环依赖问题;
  5. 填充属性,将属性填充到bean实例中;
  6. 注册DisposableBean;
  7. 创建完成并返回

三个关注点:

  1. createBeanInstance() 实例化
  2. populateBean(); 属性装配
  3. initializeBean() 处理Bean初始化之后的各种回调事件
	protected Object doCreateBean(final String beanName, final RootBeanDefinition mbd, final Object[] args)
			throws BeanCreationException {

		// Instantiate the bean.
        // 这个BeanWrapper是创建出来持有对象的
		BeanWrapper instanceWrapper = null;
		if (mbd.isSingleton()) {
            // 如果是singleton,先把缓存中的同名bean消除
			instanceWrapper = this.factoryBeanInstanceCache.remove(beanName);
		}
		if (instanceWrapper == null)
            // 关键代码,后面拉出来单独讲
			instanceWrapper = createBeanInstance(beanName, mbd, args);
		}
		final Object bean = (instanceWrapper != null ? instanceWrapper.getWrappedInstance() : null);
		Class<?> beanType = (instanceWrapper != null ? instanceWrapper.getWrappedClass() : null);
		mbd.resolvedTargetType = beanType;

		// Allow post-processors to modify the merged bean definition.
		// 涉及接口:MergedBeanDefinitionPostProcessor
		// 不是关键逻辑,不讲了
		synchronized (mbd.postProcessingLock) {
			if (!mbd.postProcessed) {
				try {
					applyMergedBeanDefinitionPostProcessors(mbd, beanType, beanName);
				}
				catch (Throwable ex) {
					throw new BeanCreationException(mbd.getResourceDescription(), beanName,
							"Post-processing of merged bean definition failed", ex);
				}
				mbd.postProcessed = true;
			}
		}

		// Eagerly cache singletons to be able to resolve circular references
		// even when triggered by lifecycle interfaces like BeanFactoryAware.
		// 这里是为了解决循环依赖的,先把初步实例化的Bean实例的引用缓存起来,暴露出去,
		// 这个可以结合别的文章学习,面试题常考,我后面可能也会写
		boolean earlySingletonExposure = (mbd.isSingleton() && this.allowCircularReferences &&
				isSingletonCurrentlyInCreation(beanName));
		if (earlySingletonExposure) {
			if (logger.isDebugEnabled()) {
				logger.debug("Eagerly caching bean '" + beanName +
						"' to allow for resolving potential circular references");
			}
			addSingletonFactory(beanName, new ObjectFactory<Object>() {
				@Override
				public Object getObject() throws BeansException {
					return getEarlyBeanReference(beanName, mbd, bean);
				}
			});
		}

		// Initialize the bean instance.
		Object exposedObject = bean;
		try {
            // 时序图中的一步,关键步骤,属性装配,前面的实例只是实例化,没有装配属性
            // 和前面的createBeanInstance一样会拉出来讲,继续看下去吧
			populateBean(beanName, mbd, instanceWrapper);
			if (exposedObject != null) {
                // 还记得 init-method 吗?还有 InitializingBean 接口?还有 BeanPostProcessor 接口?
         		// 这里就是处理 bean 初始化完成后的各种回调
				exposedObject = initializeBean(beanName, exposedObject, mbd);
			}
		}
		catch (Throwable ex) {
			if (ex instanceof BeanCreationException && beanName.equals(((BeanCreationException) ex).getBeanName())) {
				throw (BeanCreationException) ex;
			}
			else {
				throw new BeanCreationException(
						mbd.getResourceDescription(), beanName, "Initialization of bean failed", ex);
			}
		}


		// 这个逻辑分支我一次性说完吧。
		// 如果该beanName对象已经注册单例模式,则从单例中获取,并判断获取到的bean实例(B)与BeanWrapper中的bean实例(A)是同一个实例,如果是,则返回A或者B,如果不是,则递归找出它的依赖bean。
		if (earlySingletonExposure) {
			Object earlySingletonReference = getSingleton(beanName, false);
             // earlySingletonReference只有在检测到有循环依赖的情况下才会不为空
			if (earlySingletonReference != null) {
				if (exposedObject == bean) {
                    // 两个是同一个引用,bean初始化完成
					exposedObject = earlySingletonReference;
				}
				else if (!this.allowRawInjectionDespiteWrapping && hasDependentBean(beanName)) {
					String[] dependentBeans = getDependentBeans(beanName);
					Set<String> actualDependentBeans = new LinkedHashSet<String>(dependentBeans.length);
					for (String dependentBean : dependentBeans) {
						if (!removeSingletonIfCreatedForTypeCheckOnly(dependentBean)) {
							actualDependentBeans.add(dependentBean);
						}
					}
					if (!actualDependentBeans.isEmpty()) {
						throw new BeanCurrentlyInCreationException(beanName,
								"Bean with name '" + beanName + "' has been injected into other beans [" +
								StringUtils.collectionToCommaDelimitedString(actualDependentBeans) +
								"] in its raw version as part of a circular reference, but has eventually been " +
								"wrapped. This means that said other beans do not use the final version of the " +
								"bean. This is often the result of over-eager type matching - consider using " +
								"'getBeanNamesOfType' with the 'allowEagerInit' flag turned off, for example.");
					}
				}
			}
		}

		// Register bean as disposable.
		// 注册DisposableBean;
		try {
			registerDisposableBeanIfNecessary(beanName, bean, mbd);
		}
		catch (BeanDefinitionValidationException ex) {
			throw new BeanCreationException(
					mbd.getResourceDescription(), beanName, "Invalid destruction signature", ex);
		}

		return exposedObject;
	}

上一步的三个关注点,分开来讲。

1. createBeanInstance()

	protected BeanWrapper createBeanInstance(String beanName, RootBeanDefinition mbd, Object[] args) {
		// Make sure bean class is actually resolved at this point.
        // 解析出 Class
		Class<?> beanClass = resolveBeanClass(mbd, beanName);

		if (beanClass != null && !Modifier.isPublic(beanClass.getModifiers()) && !mbd.isNonPublicAccessAllowed()) {
			throw new BeanCreationException(mbd.getResourceDescription(), beanName,
					"Bean class isn't public, and non-public access not allowed: " + beanClass.getName());
		}

        // 如果工厂方法不为空,则是用工厂方法初始化
		if (mbd.getFactoryMethodName() != null)  {
            // 相关知识点看另一篇文章关于FactoryBean的
			return instantiateUsingFactoryMethod(beanName, mbd, args);
		}

		// Shortcut when re-creating the same bean...
        // 如果不是第一次创建,比如第二次创建 prototype bean。
   		// 这种情况下,我们可以从第一次创建知道,采用无参构造函数,还是构造函数依赖注入 来完成实例化
        // 所以注释说叫shortcut
		boolean resolved = false;
		boolean autowireNecessary = false;
		if (args == null) {
			synchronized (mbd.constructorArgumentLock) {
				if (mbd.resolvedConstructorOrFactoryMethod != null) {
                    // 有已经解析过的构造方法
					resolved = true;
					autowireNecessary = mbd.constructorArgumentsResolved;
				}
			}
		}
        // 如果已经解析过则使用解析好的构造方法不需要再次锁定
		if (resolved) {
			if (autowireNecessary) {
                // 构造方法自动注入
				return autowireConstructor(beanName, mbd, null, null);
			}
			else {
                // 默认构造方法
				return instantiateBean(beanName, mbd);
			}
		}

		// Need to determine the constructor...
        // 判断是否采用有参构造函数
        // 构造器自动装配
		Constructor<?>[] ctors = determineConstructorsFromBeanPostProcessors(beanClass, beanName);
		if (ctors != null ||
				mbd.getResolvedAutowireMode() == RootBeanDefinition.AUTOWIRE_CONSTRUCTOR ||
				mbd.hasConstructorArgumentValues() || !ObjectUtils.isEmpty(args))  {
			return autowireConstructor(beanName, mbd, ctors, args);
		}

		// No special handling: simply use no-arg constructor.
        // 使用无参构造器
		return instantiateBean(beanName, mbd);
	}

2. populateBean(); 属性装配

入口方法: AbstractAutowireCapableBeanFactory#populateBean

它的作用是: 根据autowire类型进行autowire by nameby type或者是直接进行设置

	protected void populateBean(String beanName, RootBeanDefinition mbd, BeanWrapper bw) {
		PropertyValues pvs = mbd.getPropertyValues();

		if (bw == null) {
			if (!pvs.isEmpty()) {
				throw new BeanCreationException(
						mbd.getResourceDescription(), beanName, "Cannot apply property values to null instance");
			}
			else {
				// Skip property population phase for null instance.
				return;
			}
		}

		// Give any InstantiationAwareBeanPostProcessors the opportunity to modify the
		// state of the bean before properties are set. This can be used, for example,
		// to support styles of field injection.
        // 这里看注解是一个扩展点
        // InstantiationAwareBeanPostProcessor 的实现类可以在这里对 bean 进行状态修改
        // 不是个常用的扩展点,这里不讲了
		boolean continueWithPropertyPopulation = true;

		if (!mbd.isSynthetic() && hasInstantiationAwareBeanPostProcessors()) {
			for (BeanPostProcessor bp : getBeanPostProcessors()) {
				if (bp instanceof InstantiationAwareBeanPostProcessor) {
					InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp;
                    // 如果返回 false,代表不需要进行后续的属性设值,也不需要再经过其他的 BeanPostProcessor 的处理
					if (!ibp.postProcessAfterInstantiation(bw.getWrappedInstance(), beanName)) {
						continueWithPropertyPopulation = false;
						break;
					}
				}
			}
		}

		if (!continueWithPropertyPopulation) {
			return;
		}

		if (mbd.getResolvedAutowireMode() == RootBeanDefinition.AUTOWIRE_BY_NAME ||
				mbd.getResolvedAutowireMode() == RootBeanDefinition.AUTOWIRE_BY_TYPE) {
			MutablePropertyValues newPvs = new MutablePropertyValues(pvs);

			// Add property values based on autowire by name if applicable.
            // 通过名字找到所有属性值,如果是 bean 依赖,先初始化依赖的 bean。记录依赖关系
			if (mbd.getResolvedAutowireMode() == RootBeanDefinition.AUTOWIRE_BY_NAME) {
				autowireByName(beanName, mbd, bw, newPvs);
			}

			// Add property values based on autowire by type if applicable.
            // 通过类型装配
			if (mbd.getResolvedAutowireMode() == RootBeanDefinition.AUTOWIRE_BY_TYPE) {
				autowireByType(beanName, mbd, bw, newPvs);
			}

			pvs = newPvs;
		}

		boolean hasInstAwareBpps = hasInstantiationAwareBeanPostProcessors();
		boolean needsDepCheck = (mbd.getDependencyCheck() != RootBeanDefinition.DEPENDENCY_CHECK_NONE);

		if (hasInstAwareBpps || needsDepCheck) {
			PropertyDescriptor[] filteredPds = filterPropertyDescriptorsForDependencyCheck(bw, mbd.allowCaching);
			if (hasInstAwareBpps) {
				for (BeanPostProcessor bp : getBeanPostProcessors()) {
					if (bp instanceof InstantiationAwareBeanPostProcessor) {
                        // InstantiationAwareBeanPostProcessor.postProcessPropertyValues方法
                        // 代表能对属性值进行修改的能力
                        // 其中一个很有用实现类提一下,AutowiredAnnotationBeanPostProcessor
                        // 对采用@Autowired和@Value设值的就是这个BeanPostProcessor干的。
                        // 不展开讲了,不然要讲不完了
						InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp;
						pvs = ibp.postProcessPropertyValues(pvs, filteredPds, bw.getWrappedInstance(), beanName);
						if (pvs == null) {
							return;
						}
					}
				}
			}
			if (needsDepCheck) {
				checkDependencies(beanName, mbd, filteredPds, pvs);
			}
		}
		// 这里才是设置bean实例的属性值
		applyPropertyValues(beanName, mbd, bw, pvs);
	}

3. initializeBean() 处理Bean初始化之后的各种回调事件

看这个方法的javadoc 描述

Initialize the given bean instance, applying factory callbacks as well as init methods and bean post processors.

	protected Object initializeBean(final String beanName, final Object bean, RootBeanDefinition mbd) {
		if (System.getSecurityManager() != null) {
			AccessController.doPrivileged(new PrivilegedAction<Object>() {
				@Override
				public Object run() {
					invokeAwareMethods(beanName, bean);
					return null;
				}
			}, getAccessControlContext());
		}
		else {
            // 涉及到的回调接口点进去一目了然,代码都是自解释的
            // BeanNameAware、BeanClassLoaderAware或BeanFactoryAware
			invokeAwareMethods(beanName, bean);
		}

		Object wrappedBean = bean;
		if (mbd == null || !mbd.isSynthetic()) {
            // BeanPostProcessor 的 postProcessBeforeInitialization 回调
			wrappedBean = applyBeanPostProcessorsBeforeInitialization(wrappedBean, beanName);
		}

		try {
            // init-methods
            // 或者是实现了InitializingBean接口,会调用afterPropertiesSet() 方法
			invokeInitMethods(beanName, wrappedBean, mbd);
		}
		catch (Throwable ex) {
			throw new BeanCreationException(
					(mbd != null ? mbd.getResourceDescription() : null),
					beanName, "Invocation of init method failed", ex);
		}
		if (mbd == null || !mbd.isSynthetic()) {
            // BeanPostProcessor 的 postProcessAfterInitialization 回调
			wrappedBean = applyBeanPostProcessorsAfterInitialization(wrappedBean, beanName);
		}
		return wrappedBean;
	}

大家发现没有,BeanPostProcessor 的两个回调都发生在这边,只不过中间处理了 init-method。这和我原来的认知有点不一样了?因为Spring的源码中代码的命名很多时候是自解释的,很多时候我看英文就知道这些方法的意图,但在这里,为什么BeanPostProcessor的前置处理方法postProcessBeforeInitialization()也是在属性设置完成后调用的?

后面查询了去看英文的解释,

BeanPostProcessor is used to interact with newly created bean instances before and/or after their initialization method is invoked by the Spring container. You can use BeanPostProcessor to execute custom logic before and/or after bean’s initialization method is invoked by the Spring container.

BeanPostProcessor的意图就是在初始化方法的前后做定制化操作。仔细想想好像这个命名也没毛病。如果真的是在SpringBean实例化之前调用应该叫BeforeInstantiation。源码中的initialization指的就是上面的invokeInitMethods操作。

结语

以上,就是关于Spring IoC 依赖注入的主要内容。

Spring IoC 容器这里还有一些其他的知识点,有关于SpringIoC 特性的。比如,Spring bean的生命周期、FactoryBean、BeanPostProcessor,都是在使用Spring IoC 容器经常遇到的特性。在了解了IoC容器的整体运行原理以后,你应该能够对这些特性进行一些分析,将你使用这些特性的方法和源码结合起来,融会贯通。

至此,Spring IoC关于依赖注入的源码“大致”解读完毕,还是那句话,上面的源码解析,肯定不会是完备的,只是提取了我认为重要的东西。

如有疏漏,敬请谅解和自己查阅相关资料学习。如果错误,敬请指正!
